Buffer 200

C
  • Storage volume V
    200 l
  • Height
    1460 mm
  • Diameter
    Φ570 mm
  • Working pressure
    0,6 (6) MPa (bar)

Technical properties

Characteristics

Energy efficiency class
C
Standing loss S
71 W
Storage volume V
200 l

Dimensions of connections

Height
1460 mm
Diameter
Φ570 mm
Heating water inlet
G1 1/4
Heating water outlet
G1 1/4
Net/gross weight/with water
55/67/255 kg

Technical characteristics

Working pressure
0,6 (6) MPa (bar)
Max. water temperature
95 °C
Non-enameled steel tank
+
Average thickness of insulation
59 mm

Accessories

Air vent pot with valve G ½
0
Discharge ball valve G ½
0
Plug G1 1/4-ZN 2 pcs
0

Transportation data

Packaging dimensions [WxDxH]
760x680x1670 mm
